Hamiltonian#

Effective-core potentials#

This feature is under implementation.

Static electric fields#

A term can be added in the Hamiltonian to describe the coupling of the molecular system and a time-independent (static), homogeneous, electric field. The value specified oin the input file are for the x,y,z direction respectively given in a.u.

Python script

import veloxchem as vlx

mol_xyz_string = """
...
"""

molecule = vlx.Molecule.read_xyz_string(mol_xyz_string)
basis = vlx.MolecularBasis.read(molecule, 'def2-svp')

scf_drv = vlx.ScfRestrictedDriver()
scf_drv.filename = 'mol-field'
scf_drv.electric_field = [0.01, 0.0, 0.0]
scf_results = scf_drv.compute(molecule, basis)

Download a Python script type of input file to perfom a scf calculation under the presence of a static electric field for the p-nitroaniline.

Text file

@jobs
task: scf
@end

@method settings
basis: def2-svp
electric field: 0, 0.001, -0.002
@end

@molecule
charge: 0
multiplicity: 1
xyz:
...
@end

Download a text format type of input file to perfom a scf calculation under the presence of a static electric field for the p-nitroaniline.
